2.2.7. Install as a VM using Proxmox VE

This chapter explains how to start a Virtual Service Router VM using Proxmox VE and the .iso file.

It expects that you already installed a Proxmox VE cluster, in which you are able to spawn VMs with network connected.

It follows the following steps:

  • make the .iso file available to Proxmox VE

  • create and configure a VM

  • boot the VM using the .iso file

  • install Virtual Service Router on the virtual disk

Upload the .iso file

Select the local storage of your node in the left pane and visualize its content:

../../_images/local_storage.png

Press the Upload button. In the pop-up window, select ISO image as content type and point to the Virtual Service Router .iso file on your local disk. Then press Upload to send this file to your Proxmox VE node:

../../_images/upload_iso.png

The .iso file is now available to this node:

../../_images/file_uploaded.png

Create and boot the VM

In the top right corner, press the Create VM button to launch the creation wizard. In General tab, check the node and the VM ID, and give a name to the VM, then press Next:

../../_images/wizard_step1_general.png

In OS tab, make sure to use the uploaded .iso file as CD/DVD and to specify a Linux with 4.X/3.X/2.X kernel as Guest OS, then press Next:

../../_images/wizard_step2_OS.png

In Hard Disk tab, keep the default qcow2 device with VirtIO SCSI storage and allocate at least 10GB, then press Next:

../../_images/wizard_step3_disk.png

In CPU tab, allocate at least 2 cores and select host as CPU type, then press Next:

../../_images/wizard_step4_cpu.png

In Memory tab, allocate at least 8GB of RAM, then press Next:

../../_images/wizard_step5_memory.png

In Network tab, bind the virtual management interface to a host bridge in order to have access to external network. Select VirtIO as model type, then press Next:

../../_images/wizard_step6_network.png

In Confirm tab, review your settings and press Finish to finalize the creation and get back to the main dashboard:

../../_images/wizard_step7_confirm.png

The VM is now available in the left pane below your physical node. Select it and review its hardware configuration:

../../_images/add_network_device_0.png

Press Add > Network Device:

../../_images/add_network_device_1.png

In the pop-up window, select an attachment bridge and choose VirtIO as model, then press Add:

../../_images/add_network_device_2.png

The second network device can now be seen in the hardware configuration of the VM:

../../_images/add_network_device_3.png

Warning

Please make sure that there is no other Virtual Service Router live CDROM or live USB inserted in this VM. Otherwise the system might fail to boot properly.

Press Start in the top right corner to actually start the VM.

The next step consists in installing on the virtual disk.

Install Virtual Service Router

Warning

Please carefully check the device associated to the disk you want to use, or you could wipe the wrong drive in the next step. When following this installation guide you have only one disk attached to the VM. Thus the device name is sda. If you attach additional virtual disks, make sure to choose the right device.

Note

Please make sure to select this disk as boot device after installation. You can access boot menu by pressing ESC at startup in the VM console.

Once the VM has booted on the .iso file, select it in the left pane of the main dashboard and press the >_ Console button to get access to the serial console.

Log in as admin, password admin, and at the prompt, do:

vsr> cmd system-image install-on-disk sda

This command will install Virtual Service Router on /dev/sda. The relevant configuration files will be copied to the local drive.

Note

To restore from a backup file, add backup-url <url> to the previous command. This will restore your configurations, private keys, certificates and licenses.

The backup file must have been generated on the same or previous minor version (e.g. a backup from 3.0.1 can be restored on 3.0.x or 3.1.x).

Reboot to finally boot Virtual Service Router from the virtual hard disk:

vsr> cmd reboot

The next step is to perform your first configuration.
